Cut and stack PDF imposition
Use PDF Press to prepare cut-and-stack sheet order for sequential print jobs. It is built for ticket, coupon, form, and small-format production teams, with local browser processing and a live preview before export.
Direct answer
What is cut and stack PDF?
Cut-and-stack imposition: pages are arranged so that after cutting, stacks are in reading order.
Also known as 'cut and stack' or 'slit and stack' layout. Pages are positioned so that after printing, cutting the sheet into strips, and stacking the strips, you get sequential page order. Saves time vs. manual collation for high-volume jobs.
How to use Cut and Stack
Upload files
Start with your source PDF or image files. Processing happens locally in the browser.
Add Cut and Stack
Configure Paper Size, White Space, Printer's Marks and any production settings that match the job.
Preview the result
Check page order, marks, scaling, and output geometry before committing the export.
Download output
Export the finished PDF for proofing, press, finishing, or another PDF Press step.
Best use cases
Key settings
Paper Size
Sets the output sheet dimensions. This is the physical paper going through your printer or press.
Standard presets: Letter (8.5×11in), Legal (8.5×14in), Tabloid (11×17in), A4 (210×297mm), A3 (297×420mm). Landscape swaps width↔height. Lock icon links dimensions to preserve aspect ratio. Custom lets you enter any size in inches, mm, or points (1in = 72pt = 25.4mm).
White Space
Controls margins around the sheet edges and gutters between items in the grid.
Left margin = space from the left sheet edge to the first column. Top margin = space from the top edge to the first row. Horizontal gutter = gap between columns. Vertical gutter = gap between rows. All values are in your selected unit (inches/mm/points). 'Center output on page' distributes leftover space evenly instead of anchoring content to the top-left corner.
Printer's Marks
Adds trim guides and alignment marks outside the live area for accurate cutting and registration.
Crop marks: short lines at each corner showing where to trim. Center marks: crosshairs at sheet midpoints for front/back alignment on duplex jobs. Line length (default 0.43in/31pt): how long each mark line extends. Line thickness (default 0.014in/1pt): mark stroke weight. Line distance (default 0.139in/10pt): gap between the mark and the artwork edge. Four-color black: prints marks in C+M+Y+K for visibility on color proofs. Knockout: adds a white halo around marks so they show on dark backgrounds.
Bleeds
Extends artwork beyond the trim edge to prevent white strips after cutting.
Three modes: 'No bleeds' trims exactly at the page boundary. 'Pull from document' uses bleed info already embedded in the PDF (TrimBox/BleedBox metadata). 'Fixed' lets you manually set bleed on each side, typically 3mm (0.125in / 9pt) for commercial print, 1-2mm for digital. Bleed values define how far past the trim edge the artwork extends.
Page Order
Controls the reading direction for cut-and-stack assembly.
Left-to-right arranges strips so that when stacked from left to right, pages are in sequential order. Right-to-left reverses the strip direction for workflows that stack in the opposite direction.
Expert tip
Cut-and-stack layout works well for irregular gang-ups where different products share a press sheet. Place the highest-quantity item first so the packing algorithm has the most room to work with.
The algorithm does not guarantee minimal waste on its own. Always check the layout preview before sending to plate.
Frequently asked questions
What is the Cut and Stack tool used for?
Cut-and-stack imposition: pages are arranged so that after cutting, stacks are in reading order.
Who should use cut and stack PDF?
It is built for ticket, coupon, form, and small-format production teams. Common use cases include Flyers, Coupons, Cut-and-Stack, High Volume.
Do my PDF files upload to a server?
No. PDF Press runs the PDF processing workflow in your browser, so your files stay on your device.
Can I use Cut and Stack with other PDF Press tools?
Yes. You can combine it with other PDF Press tools in a multi-step workflow, then preview and export the final PDF.
